GPS & Compass Module

ZST-GPSM10

High-Precision GPS+Compasass

Module for UAV Integration

Compact. Accurate.

Built for Reliable Performance.


100% Made in Taiwan

All components made from Taiwan


Ultra-Fast Output at 10Hz

Delivers real-time updates up to 10 times/sec

Compact and Lightweight Design

Sized at just 25×25×8mm and weighing only 12g

Precision Navigation with Wide GNSS Compatibility
Equipped with the advanced M10 10th-generation chip, this module supports a wide range of global satellite systems. With 72-channel tracking, it achieves 1.5m horizontal positioning accuracy and 0.05 m/s speed accuracy, enabling drones to maintain precise control even in GNSS-challenged conditions.


Ultra-Precise GPS & Compass Module – Compact. Accurate. Customizable.

With a high-sensitivity ceramic antenna and integrated QMC5883 compass, the module offers fast satellite acquisition, 10Hz update rate, and dependable flight path accuracy. It's built to meet the needs of UAV applications requiring responsive navigation and directional control.

Robust built with highly functionalities

Robust built with highly functionalities

Speed accuracy down to ±0.05 m/s and horizontal positioning within 1.5 meters.

 At just 25×25×8 mm and 12g, this unit fits easily into tight UAV builds without adding weight.Designed to endure -40°C to +85°C temperatures, altitudes up to 50,000m, and speeds of 500 m/s, it's the reliable choice for long-range, high-speed, and mission-critical drone operations.



GPS & Compass Module

ZST-GPSM10


Product Specifications
