ZST-ESC65A-4in1-S2 : Designed, Manufactured, Sealed entirely in Taiwan

April 12, 2026

Component origin hindering your procurement effort?

This importance of origin traceability and compliance will continue in 2026 as a key issue as both sides of the Atlantic have either begun or rolled out new regulations to strengthen their critical component supply chain.

The American Security Drone Act (ASDA) went into full effect on December 22, 2025, since then ritical drone components have been added to the
covered List; while several EU member states have already restricted Chinese-manufactured drones in defense and public security sectors.

The ZST-ESC65A-4in1-S2 including passive components is designed and manufactured, sealed entirely in Taiwan, built with AM32 firmware, thermal and over-current protection and NDAA compliant


65A Continuous With 8S Support: The Performance Specs


ZST-ESC65A-4in1-S2 is built to perform in demanding circumstances. Cortex-M4's DSP hardware paired with AM32 handles motor control calculations faster and in fewer processing cycles than older architectures, ensuring a smoother throttle response.
AM32 firmware supports experimental FOC modes for quieter low-speed operation: a superior alternative to BLHeli_32 for those looking for a more open-sourced option.

  • Continuous current: 65A per channel
  • Burst current: 80A peak (10 seconds) per channel
  • Voltage range: 3S–8S Li-Po (11.1V–25.2V)
  • Controller: ARM 32-bit Cortex-M4 with built-in DSP
  • Firmware: AM32 — open-source, field-upgradeable, no licensing fees
  • Protocols: PWM, DShot300, DShot600
  • Telemetry: Ammeter + telemetry support
  • Protection: Thermal + over-current
  • Mounting: 30.5 × 30.5mm, M3 screws
  • Weight: 22g

Compliance and origin shouldn’t be the bottleneck


Sunrise Taiwan is your trusted bridge between global demand and Taiwanese manufacturing excellence. We deliver one-stop, 100% non-PRC origin drone component solutions that combine in-house R&D, manufacturing capabilities, and cybersecurity expertise — helping global defense and enterprise clients accelerate certification and reduce procurement risks.



Contact us for spec sheets, compliance & origin documentation, or samples.


May 6, 2026
Introducing ZST-FL721, a 4K camera head of 19 × 19 mm weighting 8 grams, tethered to a separate 12-gram ISP board, with lens ranging from from a 60-degree wide to a 13-degree telephoto. And it works with your host, whether that's an ISP pipeline or a Raspberry Pi on raw MIPI.
April 19, 2026
Drones are increasingly operating in environments that require highly accurate heading data. They're operating under bridges, inside warehouses, and through dense urban corridors where satellite signals bounce off every surface. Defense and public safety teams are preparing for GPS-jammed environments. Drones operating in swarms also require orientation data to avoid catastrophic collisions. In these environments, your magnetic sensor is the primary heading reference. With additional conditions such as noise, temperature variables: your GPS inevitably demands a magnetic sensor that could address these issues. Where Most Sensors Fall Short Noise: A sensor with poor noise rejection picks up that interference and feeds unreliable heading data resulting in heading jumps, toilet-bowl orbits, etc. Temperature drift: Sensors with high temperature coefficients quietly corrupt heading data as conditions change, one wouldn't be able to gauge this drift at first glance. Calibration difficulties: Hard-iron and soft-iron offsets change with every new payload configuration, and recalibrating for each one creates further inefficiencies.
By rosaline989 March 2, 2026
Mercury H743 Flight Controller — Technical Deep Dive & Compliance Overview
